AluSkin Pro Dry truck body is engineered with closed-cell PU foam cores and galvanized aluminum facings, delivering lightweight design and structural stability for regional logistics fleets. The high-pressure injection process ensures a void-free foam core, providing consistent thermal performance for transporting general cargo and daily necessities.
✅ Ideal for: Long-haul Heavy-Duty, Cross-border Logistics, High-Standard Cold Chain
| Parameter | Value |
| Foam Density | 40 - 45 kg/m³ |
| Panel Material | 0.8mm Galvanized Aluminum Plate |
| Applicable Temperature Range | -30°C to +70°C |
| Standard Size | 1200mm × 2400mm (Customizable) |
| Compressive Strength | ≥ 200 kPa |
Other sizes can also be customized. The following are popular size references.
Body of Light Duty Dimension
| Parameter | Optional Dimension |
| INT. Length | 12'/14'/16'/18'/20' |
| EXT. Width | 94-1/2” |
| INT. Height | 82” |
Body of Heavy Duty Dimension
| Parameter | Optional Dimension |
| INT. Length | 16'/18'/20'/22’/24’/26’ |
| EXT. Width | 96” |
| INT. Height | 94” |
Roof panel:PU(25MM)
Side/Front panel:PU(25MM)
Floor Panel:Five-bar Texture-sheet Aluminum Floor
1 Balanced Thermal Insulation: Provides reliable thermal resistance with a typical thermal conductivity of 0.023-0.028 W/(m·K), effectively maintaining stable interior temperature.
2 Significant Weight Reduction: Contributes to an overall body weight reduction of 25%-35% compared to traditional metal structures, leading to direct fuel savings and increased payload capacity
3 Effective Strength & Filling: Offers good compressive strength (≥80 kPa). The liquid foam expands to fill complex cavities, minimizing thermal bridges and enhancing overall structural rigidity.
4 Moisture Resistant & Durable: A closed-cell structure (≥85%) effectively blocks moisture ingress, ensuring long-term performance stability and corrosion resistance.
5 Cost-Effective & Adaptable Process: The low-pressure injection process is mature and offers flexibility in production setup, representing an ideal balance between performance and cost control.
